markjkoch.bsky.social
A nice way to end the week! Got my #synth module working. Based on an open source design by Hagiwo. #RasPi #Pico2 based and using Arduino libraries, generates waves from tables or math. I added OLED and UI code. I think the PCB components need work as the output looks a little funky. #asmr-synth
October 4, 2025 at 1:20 AM
markjkoch.bsky.social
#synth rack progress! One regulator wouldn't start up, so it took a deeper read into the data sheet to realize I'd missed some components needed for voltages above 5V (a zener and cap). #Zener ended up being a stack of Zeners to achieve desired value. Not my prettiest fix. #pcb #kicad #electronics
My quad output power supply for my Eurorack alternative idea. Many engineers don't know it but you can make a typical buck regulator put out negative voltage if you swap the ground and Vout lines. The Vout is grounded and the common lines inside the circuit will output a negative potential of the desired output voltage. Feels unintuitive when designing, but works well. Also, this design uses the HUSB power negotiation chip to allow the board to be powered with a USB-PD capable laptop supply. Using the HUSB chip, those supplies can negotiate a range of output voltages like 5, 9, 12, 18 and 20V at 3 or more amperes. I'm using 20V in this design to then generate the +15, -15 and 5V needed for analog synthesizer circuits. This bodge is the missing Zener. I needed a zener of around 11.5V but only had some 3.2V laying around. So I hooked four SOT023 type in series to get close to the value I wanted. Kicking myself for not studying the data sheet more at design time. It's right there. The data sheet for this buck regulator shows that for output voltages above 12V, a zener is needed to bring the boost voltage into proper range. Once I did this, the whole thing just worked.
September 27, 2025 at 10:17 PM
markjkoch.bsky.social
I don’t have a #Mouser parts purchasing problem! I can stop any time I want. #kicad #pcb #engineering
September 24, 2025 at 3:05 AM
markjkoch.bsky.social
Upon finding this stainless steel bowl at #ikea that looks suspiciously like a half scale #R2D2 head…. Challenge accepted!
September 20, 2025 at 7:26 PM
markjkoch.bsky.social
My #JLCPCB bounty included my prototype #PCB s for a new type of rack #synth that I am thinking about. Think #eurorack but dragged into the new millennium. Backplane has two #I2C busses, slot detection, and 32 negotiated patch signals. Slightly larger such that old ER modules can nest inside.
ASMR Synth Rack backplane, ten slot, featuring PCI-type edge connectors. Not actually PCI. Mine has four voltages, 18-24V, +15, -15 and 5V. There's two I2C busses, slot detection and 32 undefined "patch" lines. The inserted synth cards can negotiate the use of the patch lines for analog audio/control voltage and digital uses. Back plane can be up to 16 slots. Currently working on a 100% 3D printable chassis design. It will be 100% open source. ASMR two slot backplane for bench development purposes. Prototype ASMR hardware as received from the PCB fabrication service. Bottom is 10 slot backplane. Bottom right is a two slot back plane. Center is three experimental boards: top is a breadboard experimenters board, middle is a power supply (USB-PD in, +/-15V and 5V out) and bottom is an implementation of Hagiwo's amazing MOD2 synth module ( I added a one inch OLED display). Right are two face plates for the rack system: The breadboard PCB faceplate and the power supply faceplate. Example of how the ASMR cards plug into the backplane. A rack chassis will be made soon to bring it all together.
September 16, 2025 at 8:11 PM
markjkoch.bsky.social
Yay! The main #PCB for my MOS #KIM-1 replica arrived today from #JLCPCB! The sub-boards seem to fit. Bringup will take awhile since there's a gross chip-pin-numbering error on one of the smaller boards and I'll have to re-fab it. But I'll be able to partially assemble it and test a few things.
My KIM-1 replica, affectionately named "KIM-1000". An all surface mount version based on the original 1970's schematic. I attempted to add a Cyberpunk-ish style to the edges. My KIM-1 replica, affectionately named "KIM-1000". An all surface mount version based on the original 1970's schematic. I attempted to add a Cyberpunk-ish style to the edges.
September 16, 2025 at 7:51 PM
markjkoch.bsky.social
When your latest #PCB uses a #PCI connector (super dirt cheap) and you want the customer to know that they should not even be tempted to plug it into a PC. I used the connector but the pinout and voltages are nowhere near those of PC Cards. At least the warning will be entertaining. #KiCAD
A Printed Circuit Board with what looks like a PCI connector edge. There is a warning imprinted onto the board that states, "Absolutely NOT PCI! Do NOT attempt to use in a computer. SMOKE, FIRE or SMELLS MAY OCCUR."
September 8, 2025 at 4:38 AM
markjkoch.bsky.social
It's alive! Keypad/Display #PCB module for my #kim-1 replica is working! Mostly based on the original 1970s #schematic, using modern parts. I wrote a PCB test fixture using Arduino and #rp2040 #raspberrypipico module from #adafruit. My first time using a rp2040 was mostly painless. #65C02
August 28, 2025 at 9:20 PM
markjkoch.bsky.social
This is a public service announcement for you to support your local PBS station! #PBS #RickSteves
World Traveller, Rick Steves, as a pickle! Support your local PBS station to keep getting more Rick.
August 15, 2025 at 4:04 PM
markjkoch.bsky.social
OK. Why not? SPOILER ALERT! ... Labeled as "Suggestive" to blur image for those who don't want to see it before it's a real thing.
KiVAD render of the MOS KIM-1000. A modern take on the KIM-1 CPU board from the 1970's. I really wanted one of the original KIM-1 boards as a kid but, being a kid, no money. However, when I reached college, my degree included theory and hands on with our very own Z-80 systems that we got to build using raw components and wire wrap! Worked the same as the KIM-1 and we even had to write our own operating program. The following semester we got to expand our Z-80s with the peripheral of our choice. I built a full robot that I'd already been working on since I was 14-ish. I programmed it to work like the "Big Track" toy. I handed all my original documentation, schematics and code to the professor to get my grade (should have made some photocopies at least). Never did get any of that back. This was a couple years before things like floppy disks and ease of and access to printers.
August 10, 2025 at 3:17 AM
